Built for speed, confidence, and usability, the E-117 Tri Disc Frameset is a classic all-around triathlon frame
The E-117 Tri Disc frameset is a fast and comfortable triathlon bike designed to meet the needs of all triathletes—young or old, experienced or novice. Featuring proven aerodynamics and triathlon-specific geometry, a highly adjustable open cockpit that allows for choice of aerobar, and our 3D system that easily accommodates athletes as they dial-in their position. Ready for your launch pad? Push yourself to the limit and discover a stronger, faster you. The perfect bike for those looking to take their IM training up a notch — without breaking the bank
Core Technologies :
3D We believe a good fit is the key to optimal performance. Argon 18’s proprietary 3D System is an integrated solution that extends the headtube for more flexible positioning options. Three headtube positions are possible for every frame size, increasing stiffness by 5% at 15mm and 11% at 25mm, versus traditional spacers. It allows also a larger fit windows (60mm of stack adjustment compared with 30 for a traditional setup). With this system, the handlebar height can be perfectly adjusted to meet the needs and preferences of every rider.
Triathlon and TT Geometry Tri and TT bikes prioritise aero performance, and the geometry of these bikes reflects this. To allow the rider to achieve an aggressive aero position, the seat tube angle is much steeper than on a traditional road bike. This geometry is designed to put the rider in a more forward position. Not only does this help with aerodynamics, it also can help save a triathlete's legs for the run, as it places less stress on the quadriceps. While a TT rider doesn't have to worry about running a marathon after the ride, the same aggressive aero positioning is required to shave precious seconds off the course. Argon 18's triathlon and TT geometry maximises performance while allowing riders to dial in their perfect fit to maintain that position throughout the race.
Argon Fit System - The Argon Fit System is designed to provide riders of all sizes with consistent performance and optimal positioning. Regardless of your build, gender or your riding style, our frames are designed so that your fit will always be efficient and comfortable, ensuring the ultimate in handling. We offer sizing from XXS to XL in all of our road bikes, and XS to XL in our Tri bikes, with each size approached individually from a design and performance perspective. While a lot of manufacturers optimise performance and weight targets for a medium size frame and simply scale up or down, we assess the performance of each size based on the individual character of that particular geometry. For example, even our largest frames have exceptional stiffness without excess weight, to avoid the 'dead' feel found in some XL frames. XS and XXS retain their inherent lightweight qualities, but without excess stiffness, avoiding harsh ride quality.
Cyclosportif Layup - Best in class without breaking your bank. We want everyone to experience the true essence of Argon 18 bikes. Newcomers to the sport or seasoned cyclists on a budget choose our Cyclosportif level models because of their proven design platforms, carbon layup derived from our Pro-level models, and performance-oriented handling and ride quality.
|Seat Tube (ctr-top)||465||510||525||555||590|
|Seat Tube (ctr-ctr)||-||-||-||-||-|
|Effective Top Tube||492||504||517||528||545|
|Actual Top Tube||-||-||-||-||-|
|Seat Angle (°)||78||78||78||78||78|
|Head Tube Angle (°)||72||72||72||72||72|
|Head Tube Length||84||94||114||138||165|
|Saddle Height Min.||640||685||700||730||765|
|Saddle Height Max.||785||830||845||875||910|
|FRAME||Argon 18 E-117 Tri, carbon rim brake|
|FORK||Argon 18 E-117 Tri, carbon, rim brake|
|HEADSET||FSA 37E + 3D 1" 1/4|
|BOTTOM BRACKET||BB86 - available to be purchased separately|
|SEATPOST||Argon 18 ASP-7050 carbon|
|BRAKE CALIPERS||Argon 18|
|CLAIMED FRAME WEIGHT||1,405 grams, size medium, painted with no small parts|
|CLAIMED FORK WEIGHT||398 grams|
